WORKING PRINCIPLE
The working principle of a high shear mixing granulator is that in a WHL cylindrical (conical) container, the powder material and adhesive are mixed into a moist soft material through a mixing paddle at the bottom. Then, they will be cut into uniform wet particles by high-speed broken blades on the side.
TECHNICAL PARAMETERS
|
Type |
WHL-50 |
WHL-150 |
WHL-200 |
WHL-250 |
WHL-300 |
WHL-400 |
|
Volume (L) |
50 |
150 |
200 |
250 |
300 |
400 |
|
Capacity (kg/batch) |
15 |
50 |
80 |
100 |
130 |
200 |
|
Blending speed (rpm) |
300/210 |
270/180 |
270/180 |
188/130 |
160/110 |
120/85 |
|
Blending power (KW) |
4/5.5 |
9/11 |
11/14 |
11/14 |
11/14 |
15/17 |
|
Cutting power (KW) |
1.5/2.2 |
2.4/3 |
3.3/4 |
3.3/4 |
4.5/5.5 |
6.5/8 |
|
Cutting speed (rpm) |
1440/2900 |
|||||
|
Working time (min) |
8-15 |
|||||
|
Particle size (mesh) |
20-80 |
|||||
PRODUCT FEATURES
The WHL stainless steel powder injection adhesive wet particle mixing granulator is suitable for pharmaceutical, food, chemical and other fields. High shear granulators are used in the pharmaceutical industry to produce granules, tablets, and capsules.
PRODUCT APPLICATION
1. Pharmaceutical industry: High shear granulators are often used in the production of granules for tablets and capsules in pharmaceutical enterprises.
2. Food industry: High shear mixing granulators can be used in the food industry to mix and granulate ingredients for products such as energy bars and nutritional supplements.
3. Chemical industry: Wet mixing granulators can be used for mixing and granulating powders in the chemical industry, for producing fertilizers and other chemical products.
