This icing sugar grinding machine can grind sugar to 12-120mesh,can make fine sugar powder. It can work continuously 24 hours. If you want grinding machine get large capacity or want simple operation,WLF pulse cyclone grinder is a good choice.
This icing sugar grinding machine can grind sugar to 12-120mesh,can make fine sugar powder. It can work continuously 24 hours. If you want grinding machine get large capacity or want simple operation,WLF pulse cyclone grinder is a good choice. Because clients only need to pour sugar into the feeding hopper,the sugar powder will go out automatically from the discharge part,no need to adjust or install grinder machine,very easy and convenient for clients.
This icing sugar grinding machine use pin blade as grinding blade. Pin blade is composed of several hexagonal cyclinder,the cyclinder is thick and hard,normally use,the grinding blade can use for 6 years. So our WLF grinder machine have very long use time. When machine working,the grinding blade will rotary at a high speed which can quickly cut and grind material to powder,so WLF pulse cyclone grinder is high efficient. WANLING company all use new quality motor and stainless steel to make machine,so our machine can work stable and have good grinding effect and have long use time.many clients like our grinder machine.
| Type | 20B | 30B | 40B | 50B | 60B |
| Capacity（kg/h） | 20-80 | 50-300 | 100-400 | 300-500 | 300-500 |
| Main Speed (r/min) | 4500 | 3500 | 3400 | 2900 | 2900 |
| Feed Size (mm) | 6 | 10 | 12 | 12 | 12 |
| Discharge Size（mesh） | 20-150 | 20-150 | 20-150 | 20-150 | 20-150 |
| Crush Power (kw) | 4 | 5.5 | 7.5 | 11 | 22 |
| Fan Power(kw) | 2.2 | 2.2 | 2.2 | 3 | 3 |
| Discharge motor(kw) | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| Weight(kg) | 350 | 500 | 600 | 750 | 750 |
| Overall Dimensions(mm) | 1000*800*1600 | 1200*850*1780 | 1480*900*1890 | 1580*1000*2000 | 1800*1200*2200 |
1. Food: sugar powder can be used in spice,cake,seasoning and etc.
2. Health products:sugar powder is rich in nutrients and can be used in health products to promote blood circulation and enhance immunity.
3. Drugs: sugar powder can be used in traditional Chinese medicine formulas, which has the functions of dispelling cold and relieving pain, expelling wind and dehumidification.
In a word, pin mill machine is a kind of equipment specially used to process sugar into powder.
Dear friend,we are professional and reliable company,we have opened for more than 20 years,our machine processing technology is very mature and our company development is very good,we have received many certificates and customer recognition,we are famous in wuxi,if you are interestedin our machine,welcome to contact us.
